Autodesk Inventor Nastran 2025 | 1 Year Student License | Digital Delivery

Description

What is Autodesk Inventor Nastran?
Autodesk Inventor Nastran® delivers finite element analysis (FEA) tools for engineers and analysts.

Powered by the widely accepted Autodesk Nastran solver technology

Wide range of simulation study types for nonlinear, dynamics, heat transfer, fatigue, and more

Highly tested through a comprehensive verification program and documentation set using NAFEMS

Why use Autodesk Inventor Nastran 2025?
Improve product performance
Choose from a complete portfolio of powerful study types to help you optimize your design.

Reduce warranty issues
Go beyond linear static study types and analyze the effects of recurring loads in a fatigue study.

Decrease time to market
Analyze your designs early and often right inside Inventor to reduce the number of physical prototypes.

Features of Autodesk Inventor Nastran 2025
Heat transfer

Analyze the effects of convection, conduction, and radiation on your design to avoid failure due to excessive temperatures. Use those results to solve for an accurate thermal stress study. (video: 2:38 min.)
Video: Demo of a brake assembly subjected to steady-state thermal heat transfer analysis
Automated drop test

Use intuitive tools to set up the initial velocity and acceleration for an impact analysis. (video: 1:51 min.)
Video: An automated drop test analysis showing the dropping of a shelf onto the floor
Advanced material models

Gain highly accurate results by using advanced material models for plastic, rubber, soft tissue, and more in a nonlinear study type. (video: 4:20 min.)
Video: Non-linear options available in the material library for this hedge-trimmer assembly
Linear static

Quickly solve linear static studies to learn where you have high concentrations of stress, strain, or displacement in your design. (video: 1:42 min.)
Video: A demonstration on how to run linear static stress analyses with Nastran without using physical prototypes
Bolt connectors

Connect parts in your assemblies with bolt connections to reveal fastener concerns or ways to optimize and reduce the number of bolts needed. (video: 4:01 min.)
Video: This 3D model helps you visualize load conditions and select the number of bolts
Autodesk CFD interoperability

Import data from Autodesk CFD and include the temperature or pressure as a loading condition for highly accurate results in Inventor Nastran. (video: 53 sec.)
Video: A temperature test analysis of a valve model set up in Autodesk CFD
Response spectrum analysis

Run a quick analysis that includes number of modes, damping, and response spectrum data. (video: 1:18 min.)
Video: A simple building model to test various Nastran options for analyses
Automatic midplane mesher

Gain faster and more accurate bending results when using shell elements for thin components. (video: 1:11 min.)
Video: A demonstration of using thin shell elements for speed and accuracy of results
Frame Generator idealization

Solve for bending moment, bend diagrams, and axial stress when using beam elements for structural members. (video: 2:13 min.)
Video: A demonstration of how Frame Generator and Nastran work together seamlessly
Linear buckling

Analyze structures, such as columns and beams, for catastrophic failure under certain loading conditions. (video: 47 sec.)
Video: Learn how to analyze designs and materials to avoid catastrophic buckling failures
Static fatigue

Determine the durability of structures under repeated loading, including low- and high-cycle fatigue.
Impact analysis

Solve impact events and drop testing of all types of nonlinearities at the same time.
Surface contact

Accurately simulate and model parts with different kinds of contact, such as sliding, friction, and welding.

System Requirements
The tables below show the minimum, budget, and high-end system and hardware requirements for workstations and laptops necessary to achieve maximum performance with Autodesk Inventor Nastran and Autodesk Nastran. There are no special hardware requirements for the Nastran products beyond those imposed by Microsoft® Windows®.

Note: Autodesk Inventor (Standard or Professional) 2021 must be installed before installing Inventor Nastran 2021. If you are installing Autodesk Nastran on a Linux operating system, Autodesk Inventor Nastran 2025 is not required.
Windows Operating System

(desktop workstations or laptops)

64-bit Microsoft Windows 10
Linux Operating System (Autodesk Nastran only)

RedHat or CentOS 7 or 7+, glibc 2.17 or 2.17+
libstdc++/compat-libstdc++ 5.3.1 or 5.3.1+

Network Card Required for network installation with FlexLM licensing for all workstations or laptops.
Linux Operating System Requirements
The Linux version of Autodesk Nastran is built on CentOS 7. We recommend you use version 7 or newer of this Linux distribution. This release will also work on Red Hat Enterprise Linux 7 versions. Support for Red Hat Enterprise Linux 5 and 6 has been discontinued.

Autodesk Nastran may work on other Linux distributions which are not officially supported. On other Linux distributions, binary compatibility of Autodesk Nastran requires that a specific version, or greater, of two core system components be installed. These system components are the glibc library and the libstdc++ library. The version of the libstdc++ library is usually tied to the version of gcc on your system. Additionally, newer Linux distributions may have moved the required libstdc++ libraries to a “compat-libstdc++” package. Please consult your distribution’s documentation to learn how to determine the versions you have installed. Alternatively, websites such as http://www.distrowatch.org maintain databases of the versions of components available with specific distributions. The table below summarizes the requirements.

We recommend you upgrade to the latest stable version of Linux. The improvements in performance, security, and reliability may be beneficial – even if you only use Autodesk Nastran occasionally. Installation requires a number of standard system utilities such as gzip, tar, sed, grep, and bash which are most likely installed by default on your system. If you find these are missing, please ask your system administrator to install.

Desktop Workstation Specifications:

Minimum Workstation Budget Workstation High-End Workstation
Computer, CPU 2.5 GHz or greater 3.0 GHz or greater 3.0 GHz or greater, 8 or more cores
Memory, RAM 8 GB 16 GB 32 GB+
Graphics Card 1 GB dedicated video card, DirectX 11 compliant 2 GB dedicated video card, DirectX 11 compliant 4+ GB dedicated video card, DirectX 11 compliant
Hard Disk 40 GB free space 1 TB SSD 2 TB SSD with fast read/write speeds
Laptop Specifications:

Minimum Laptop Budget Laptop High-End Laptop
Computer, CPU 2.5 GHz or greater 3.0 GHz or greater 3.0 GHz or greater, 4 or more cores
Memory, RAM 8 GB 16 GB 32 GB+
Graphics Card 1 GB dedicated video card, DirectX 11 compliant 2 GB dedicated video card, DirectX 11 compliant 4+ GB dedicated video card, DirectX 11 compliant
Hard Disk 40 GB free space 512 GB SSD 2 TB SSD with fast read/write speeds
There are many types of hardware that will allow you to use Inventor Nastran and Autodesk Nastran. Proper choice of hardware, however, can often make the difference between frustration and productivity. Here are a few suggestions:

Add more memory (RAM) above the minimum configuration. This will allow you to specify more memory for the Nastran products and reduce the likelihood of memory thrashing (excessive paging of virtual memory to disk).
Hard disk space recommendations are general guidelines only. User requirements can vary considerably, especially when using large models.
Purchase or upgrade to the latest versions of Windows. The improvements in performance and reliability will more than outweigh the initial cost – even if you only use the Nastran products occasionally.
See also System Requirements for Autodesk Inventor 2021.

Parent topic: Installation Supplement for Autodesk Inventor Nastran and Autodesk Nastran
